ZSK Web API

CreateTC

POST

Creates TC (Z00) stitch data.

Parameters

Parameter	Type	Description	Required
`RequestType`	string	Defines the request type	Yes
`EmbroideryType`	string	Defines the type of the embedded embroidery data	Yes
`EmbroideryBase64`	string	Base64 encoded embroidery data	Yes

Example

{
	"RequestType": "CreateTC",
	"EmbroideryType": "TC",
	"EmbroideryBase64": "8AHK...",
	"Monograms": [
		{
			"Text": [
				"Heart"
			],
			"FontFamily": "Arial",
			"FontSizeMM": 10.0,
			"UsedNeedle": 2,
			"TextStitchParameter": "Premium"
		}
	],
	"Needle": [
		{
			"Red": 196,
			"Green": 30,
			"Blue": 58,
			"ColorName": "radiant red",
			"ColorNumber": "5566",
			"ThreadSize": "40",
			"Name": "ISACORD"
		},
		{
			"Red": 0,
			"Green": 0,
			"Blue": 0,
			"ColorName": "Black",
			"ColorNumber": "20",
			"ThreadSize": "40",
			"Name": "ISACORD"
		}
	]
	"Rotation": 0,
	"TextAlignment": {
		"Mode": "Bottom",
		"Alignment": 1,
		"DistanceMM": 0,
		"xPosMM": 0.0,
		"yPosMM": 0.0
	},
	"ServerVersion": 3
}
